MOT-CG125
MOTOR NUEVO CON NUMERACION. ORIGEN: CHINA. NO INCLUYE COLOCACION.
GARANTIA EN CASO DE DEFECTO DE FABRICA EN SUS COMPONENTES.
ACONSEJAMOS SEA COLOCADO POR SU MECANICO DE CONFIANZA.
CG125 TECHNICAL SPECIFICATION
1. Engine type: single cylinder, 4 stroke, air cool, vertical
2. Bore and stroke mm*mm 56.5×49.5
3. Displacement ml 124ml
4. Compression ratio 9.0:1
5. Power and rev 6.8KW/7500r/min
6. Torque and rev 8.5N.m/7000r/min
7. Min. Fuel consumption: 367g/KW.h
8. Spark advance angle 27º±2º
9. Valve clearance cold state: intake valve: 0.03mm
exhaust valve:0.05mm
10. Fuel number RQ-90
11.Oil number : 15W/40
12.Oil consumption 8g/KW.h
13.Transmission ratio elementary 4.055
* 1 gear 2.769
* 2 gear 1.882
* 3 gear 1.400
* 4 gear 1.130
* 5 gear : 0.960
14. Spark plug type D8RTC
15. Spark plug gap 0.6-0.7
16. Lgnition type C.D.I breakerless ignition
17. Clutch type: Multi plate oil bath type, manually operated clutch
18. Lubrication type Pressure splash
19. Oil capacity 1.1L
20. Transmission case type Five international files
21. Starting type Electric/ Kick start
22. Oil pump type: Internal engagement rotor type
23. Magneto type: Flywheel rotor type
24. Exhaust contaminant: CO 4.5% HC 1200ppm
25. Dimension 330×318×390
26. Net weight 32±1Kg
